Energiespeicher FOXTHEON P100
| PERFORMANCE | P60MAX | P100 | ||||||||
| Nominal rated power | kVA | 100 | ||||||||
| Overload power(60s) | kVA | 125 | ||||||||
| Nominal peak power(10s) | kVA | 250 | ||||||||
| ELECTRICAL | ||||||||||
| Rated voltage | VAC | 400 | ||||||||
| Output voltage range | VAC | 400 (-10%~+15%) | ||||||||
| Frequency | Hz | 50/60 | ||||||||
| Power factor range | 0 ind. …1 … 0 cap | |||||||||
| Nominal rated AC current | A | 144 | ||||||||
| Max AC current(10s) | A | 360 | ||||||||
| ENERGY | ||||||||||
| Cell chemistry | LiFePO4 | |||||||||
| Nominal capacity | kWh | 102 | ||||||||
| Effective capacity | kWh | 918 | ||||||||
| Recharging time | Hours | 2h@51kW | ||||||||
| Discharging time | Hours | 1h@92kW | ||||||||
| System round trip efficiency | % | up to 96% | ||||||||
| DoD% (depth of discharge) | % | 90 | ||||||||
| Lifetime (80% DoD) | Cycles | 7000 | ||||||||
| Battery management system | Automotive grade BMS | |||||||||
| Battery balanced (recharge up to 100%) |
4 weeks | |||||||||
| Temperature control | Liquid cooling / PI heating film | |||||||||
| ENVIRONMENTAL | P60MAX | P100 | ||||||||
| Protection class | IP54 | |||||||||
| Corrosion protection | C3 (C5M) | |||||||||
| Operating temperature | ℃ | -20 to +50 | ||||||||
| Humidity | 0-95%（no condensation） | |||||||||
| Maximum operating altitude | m | 3000 | ||||||||
| Sound power level | dB(A) @1m |
<50 | ||||||||
| MECHANICAL | P60MAX | P100 | ||||||||
| Dimensions (L x W x H) | mm | 2300*1150*2200 | ||||||||
| Weight | kg | 2200 | ||||||||
| CONTROL | |||||||||
| Control panel | Industrial-grade touch-enabled 10”HMI with configurable presets, data vi- sualisation and logs | ||||||||
| Protection | Overload, Overheat, Short Circuit, Earth Fault | ||||||||
| Temperature control | Active forced air cooling | ||||||||
| Remote generator start | Dry contact relay / MODBUS | ||||||||
| Remote connectivity | Data-efficient M2M communications via cellular IoT and user notifications to Internet connected devices |
||||||||
| Remote automation | FoxCloud Web APP | ||||||||
